Onemed M108 Mesh Nebulizer

Onemed M108 Mesh Nebulizer

The ONEMED M108 Mesh Nebulizer is a portable inhalation device designed to convert inhalation liquid medication into aerosol so that it can be inhaled through the respiratory tract according to the usage instructions. With a compact design, this device is practical to use at home or while traveling to assist with respiratory therapy as recommended by medical personnel.

Product Specifications

• Brand: ONEMED

• Model: M108

• Type: Portable Mesh Nebulizer

• Power supply: 5V, 1A AC-DC adapter or 2 AA batteries (not included)

• Power consumption: Less than 3 W

• Ultrasonic frequency: Approximately 110 kHz

• Safety level: Type BF

• Maximum nebulization rate: More than 0.2 ml/min

• Liquid capacity: Minimum 0.5 ml and maximum 8 ml

• MMAD: Less than 5 µm

• FPD: More than 60%

• Low battery indicator: 1.9 V ± 0.2 V

• Automatic shut-off: Yes, when the liquid is depleted

• Cleaning mode: Available

• Dimensions: 108 × 75 × 45 mm

• Indonesian Ministry of Health distribution permit number: AKL 20403620057

Product Functions

• Assists in administering inhalation medication in aerosol form according to prescriptions or medical instructions.

• Supports respiratory disorder therapy, including asthma, according to the indication of the medication used.

• Helps deliver inhalation medication so that it can be inhaled through the respiratory tract.

• Supports inhalation therapy usage at home with a portable device.

Benefits and Advantages

• Portable design: Compact size making it easy to carry and store.

• Flexible power source options: Can be used with an adapter or two AA batteries.

• Efficient nebulization: Nebulization rate of more than 0.2 ml/min per product specifications.

• Aerosol particle size: MMAD less than 5 µm.

• Automatic shut-off feature: Helps prevent the device from continuing to operate when the liquid is depleted.

• Cleaning mode: Supports device maintenance according to manufacturer instructions.

• Practical use: Can be a choice of inhalation therapy device for use at home or while traveling.

Key Features

1. Portable mesh nebulizer technology.

2. Ultrasonic frequency of approximately 110 kHz.

3. Liquid capacity of 0.5–8 ml.

4. Nebulization rate greater than 0.2 ml/min.

5. Low power, less than 3 W.

6. Power source via 5V/1A adapter or 2 AA batteries.

7. Automatic shut-off when liquid is depleted.

8. Cleaning mode available.

9. Compact size 108 × 75 × 45 mm.

10. Registered with Indonesian Ministry of Health distribution permit number AKL 20403620057.

Instructions for Use and Maintenance

• Use only inhalation liquids or medications that comply with the manufacturer's instructions and medical personnel recommendations.

• Follow the assembly and operating instructions before using the device.

• Clean the components according to the manufacturer's instructions after use.

• Do not submerge the electronic parts or clean components using methods not recommended.

• Ensure the device and components are clean before storing.
